Crankshaft right bearing bushing disassembly
• Remove roller (1).
Warning
Burn hazard in case of contact with hot/heated parts.
Should you have to touch hot parts, wear protective gloves.
• Remove bushing (1) using a suitable pre-heated puller.
Technical specications
Pre-heating tempera-
ture of puller for main
bearing inner rings
300 °C
• Apply puller around the bushing (1).
After a reduced heating phase, remove bushing
Crankshaft for countershaft gear disassembly
• Remove space washer (1), if any.
• Mark assembly position on gear (2), and on crankshaft.
• Remove gear (2) with M6 screws (3).
• Remove reference pins (4).
