Husqvarna TE511 - Lubrication Points (Lubricant)

Y.4
H006232
A
A
A
D
B
C
C
E
E
A
A
1
1
H006231
1
st
edition (08-2010) _Rev. 11-2010
CHASSIS AND WHEELS
Lubrication points (lubricant)
1 Steering bearings (grease)
Check the assemblies shown in the gure
for cracks or damage.
If any are found, replace the part.
A ENGINE RETAINING PINS/SCREWS
B ENGINE MOUNTING LINKS
C REAR CHASSIS MOUNTING BOLTS
D CHAIN GUIDE ROLLER/BEARING
E FOOTPEGS/PINS/SPRINGS
