Crankshaft left bearing bushing disassembly
Warning
Burn hazard in case of contact with hot/heated parts.
Should you have to touch hot parts, wear protective gloves.
• Remove bushing (1) using a suitable pre-heated puller.
Technical specications
Pre-heating
temperature of puller
for main bearing inner
rings
300 °C
• Apply puller around the bushing (1).
After a reduced heating phase, remove bushing
Crankshaft axial clearance adjustment
• Measure crankshaft at the bearing seats (arrows), and divide the read value
(A) by 2 (A1).
Technical specications
Crankshaft reference
block
Dimension at
34.55
+0.05
mm
0
• Add to A1 the value read (B) by timing chain gear.
Technical specications
Timing chain control
gear width
9.2 mm
