Husqvarna TE511 - Replacing Output Shaft Oil Seal; Gearbox Output Shaft Left Oil Seal Disassembly; Gearbox Output Shaft Right Oil Seal Disassembly; Gearbox Output Shaft Right Oil Seal Assembly

F1.68
H01998
H01999
H01999
H01998
ENGINE DISASSEMBLY/REASSEMBLY
1
st
edition (08-2010) _Rev. 11-2010
Replacing output shaft oil seal
Gearbox output shaft left oil seal disassembly
• Remove oil seal (1).
Gearbox output shaft right oil seal disassembly
• Remove oil seal (1).
Gearbox output shaft right oil seal assembly
• Fit the new oil seal (1) using a suitable tool.
Gearbox output shaft left oil seal assembly
• Fit oil seal (1) using a suitable tool.
