Fuel supply hose inspection
Check fuel supply hose conditions; if cracked, swollen etc. it is necessary
to change it as follows:
- Remove the saddle and left-hand side panel, as described in the relevant
paragraphs.
- Release the control unit (1) off its mounts and remove it from its housing.
- Using a Phillips screwdriver, loosen the clamp (2) connecting the tube (3)
to throttle body (4).
- Remove the front tank (tank with pump) as described in the corresponding
paragraph.
- Slide the tank (5) with tube (3) connected off the bike.
- Using the suitable pliers, open clamp (6) and remove tube (3) from
the fuel pump.
- Reassemble all parts, in the reverse order compared to disassembly.
