J.3
1
H006175
2
H006176
H006244
H006178
1
st
edition (08-2010) _Rev. 11-2010
REAR SUSPENSION
Rear shock absorber
TIGHTENING TORQUE FIGURES
1, 2 = 50 Nm/ 5.0 Kgm/ 36.88 ft-lb
Lubrication points (grease)
