F1.15
H01727
H01712
H01713
8000H5009
ENGINE DISASSEMBL
Y/REASSEMBL
Y
1
st
edition (08-2010) _Rev
. 1
1-2010
Engine positioning at ignition TDC
•
T
urn engine until reaching
TDC.
•
Reference marks (arrows) parallel with cylinder head.
Securing crankshaft at TDC
•
Remove screw (1) with sealing ring.
•
Lock crankshaft at
TDC using special tool (8000H5009).
