CDI electronic control unit removal
- Remove the saddle as described in the relevant paragraph.
- Remove the connector (1) from the CDI electronic control unit (2) and take
the control unit together with its anti-vibration mount out of the chassis.
Voltage regulator removal
- Remove the saddle as described in the relevant paragraph.
- Loosen the screws (1) using a 8 mm wrench.
- Disconnect the connector (2), and remove voltage regulator (3).
