Battery removal
- Remove the saddle as described in the relevant paragraph.
- First remove the BLACK negative cable (1), then the RED positive cable (2)
(when reassembling, rst connect the RED positive cable, then the BLACK
negative cable); release retaining elastic strap (3), and remove battery (4)
from its compartment.
Tank Removal
- Close both fuel cocks (1).
- Remove the saddle and the two side panels, as described in the relevant
paragraphs.
- Release the electronic control unit (2) off its mounts, and move it aside.
