Husqvarna TE511 - Page 66

E.8
H06516
3
H02416
4
H02417
5
6
1
st
edition (08-2010) _Rev. 11-2010
GENERAL PROCEDURES
- Undo the upper clamp (3) connecting fuel pump to throttle body.
- Disconnect pump supply connector (4).
- Slacken clamp (5) with long nose pliers, and disconnect breather hose (6)
from tank.
