- Slacken clamp (7) with long nose pliers, and disconnect hose (8) between
the two tanks.
- Loosen upper screw (8) using a 14 mm wrench; undo and remove lower
bolt (9) with two 14 mm wrenches, then remove engine left connecting rod
(10).
as for TC model, remove exhaust manifold as described in the relevant
paragraph to undo bolt (9).
On reassembly, position connecting rod (10) with the written side facing
the inner part of the bike, to a tightening torque of 50 Nm - 5.0 Kgm - 36.88
ft/lb + loctite 243.
