- With a 8 mm socket wrench, undo screw (11), and remove the screw with
rubbers and spacers.
On reassembly, tighten screw (11) to 10 Nm - 1.0 Kgm - 7.38 ft/lb.
- Remove tank (12) and drain any residual fuel through cock.
For upper tank removal, refer to the rear chassis removal paragraph.
