E.19
TC
H02450
4
6
5
7
3
2
1
8
1
st
edition (08-2010) _Rev. 11-2010
GENERAL PROCEDURES
Exhaust system removal (TC).
Key
Silencer1.
Spring 2.
Manifold3.
Spring4.
Flange5.
Bushing6.
Seal7.
Nut8.
