Husqvarna TE511 - Page 76

E.18
H02446
6
H02447
8
7
H02449
9
1
st
edition (08-2010) _Rev. 11-2010
GENERAL PROCEDURES
- Cut Lambda sensor cable clamps, and remove connector (6).
- Loosen the two screws (7) using a 12 mm Allen wrench, then remove manifold
(8)
- On reassembly, replace seal (9)
