• Apply a layer of sealant onto rubber sheath (2) sealing surfaces.
Consumables
3 - Bond 1209 Surface sealer
• Position retaining plate (4), and pulse transducer (3).
• Insert rubber sleeve (2)
• Tighten screws (1).
Tightening torque gures
Pulse transducer onto engine left crankcase cover
M5 x 12 - 10.9, Microincapsulated
screw replacement
6 Nm
