• Remove idler gear (1) using a suitable tool.
Technical specications
Release/connection
temperature
80 °C
Check
• Check bearing (1).
Result: Bearings do not move properly or they have increased clearance.
Action:
• Replace bearings.
Check
• Check bearing points (2).
Result: Damaged or widened bearing points.
Action:
• Replace crankcase cover.
• Replace crankcase
• Insert idler gear (1) inside locking tool (N. 8000H5020).
• Apply an insert for socket wrench (N. 8000H5767) onto clutch.
Check
• Check starting torque.
Technical specications
Clutch check torque
inside primary drive
unit
New 190...250 Nm
Wear limit Min. 140 Nm
Result: Clutch does not reach nominal value.
Action:
Replace idler gear (crankcase cover removed)
