Key to wiring diagram
1. Control unit
2. Neutral
3. Crankshaft pick up
4. Second throttle motor
5. Air temperature sensor
6. MAP sensor
7. Injector
8. Second throttle sensor
9. Lambda sensor
10. First throttle sensor
11. Coil ground
12. Ignition coil
13. Coolant temperature sensor
14. Generator
15. Chassis wiring connector
16. Diagnostics
17. Power relay
18. Fuel pump relay
19. Fuel pump
20. Map change connector
21. Solenoid starter
22. Engine ground
23. Condenser
24. Diode connector
25. Fan relay
26. Fan
Colour coding key
blge ............... Blue/Yellow
blgn ............... Blue/Green
blrt................. Blue/Red
blsw .............. Blue/Black
br .................. Brown
brbl................ Brown/Blue
brge .............. Brown/Yellow
brgr ............... Brown/Grey
brsw .............. Brown/Black
brvi ................ Brown/Violet
brws .............. Brown/White
gebl ............... Yellow/Blue
gebr .............. Yellow/Brown
gegn.............. Yellow/Green
gert ............... Yellow/Red
gnbl ............... Green/Blue
gnge.............. Green/Yellow
gngews ......... Green/Yellow/White
gnsw ............. Green/Black
grvi ................ Grey/Violet
rt ................... Red
rtbl................. Red/Blue
rtgn ............... Red/Green
rtws ............... Red/White
sw ................. Black
swgn ............. Black/Green
swrt ............... Black/Red
wsbl .............. White/Blue
wsbr .............. White/Brown
wsge ............. White/Yellow
wsgn ............. White/Green
wsrt ............... White/Red
wssw ............. White/Black
wsvi ............... White/Violet
