10) Voltage regulator connector
The following connectors are positioned on the bike left side:
11) Main starting relay connector
12) Fuel pump relay connector
13) Air temperature sensor connector
14) Coil connector
15) Condenser connector
The following connectors are positioned under the saddle:
16) Electronic control unit connector
17) Solenoid starter connector
