3.8 I/O Signals
A3-101
ME0384-4A
(1) Zone signal (ZONE1, ZONE2)
Turns ON in any range set in the parameter.
Set the zone range in the following parameters.
(1) ZONE1 :
Parameter No. 1 (zone boundary 1 + side), parameter No. 2 (zone boundary 1 - side)
(2) ZONE2 :
Parameter No. 23 (zone boundary 2 + side), parameter No. 24 (zone boundary 2 - side)
The zone signal is valid during drive source cutoff after home return is completed as long as the
home is not lost due to an alarm or the like.
(2) Position zone signal (PZONE)
Turns ON in any range set in the position table.
No.
Position
[mm]
Speed
[mm/s]
Acceleration
[G]
Deceleration
[G]
Push
[%]
Threshold
[%]
width
Zone+
[mm]
Zone-
[mm]
deceleration
Incremental
set
Stop
mode
0
1 0.00
250.00
0.20
0.20
0
0
0.10
50.00
30.00
0
0
0
0
2 100.00
250.00
0.20
0.20
0
0
0.10
70.00
60.00
0
0
0
0
3 50.00
250.00
0.20
0.20
50
0
20.00
60.00
65.00
0
0
0
0
The zone range is set in the position table.
During the execution of the position No. for which the zone range is set, its set value will be
enabled. It is valid during drive source cutoff even after it is stopped as long as the actuator is
operated and the home is not lost due to an alarm or the like.
Setting the zone range
To Next Page
