3.8 I/O Signals
A3-105
ME0384-4A
Specifications Section
Chapter 3 Gateway Unit
[11] Jog speed / inching distance switching (JVEL) PLC output signal
Operation mode
Direct numerical control
Simple direct
Positioner 1 Positioner 2 Positioner 3 Positioner 5
: Y
×
: N
×
This is a parameter switching signal that specifies the speed and inching distance during jog
and inching (incremental) operation.
It changes as follows according to the JVEL signal, JISL signal and field network control mode.
JVEL signal
Jog operation: JISL = OFF Inching operation: JISL = ON
OFF
Parameter No.26
"PIO Jog velocity"
Parameter No.26
"PIO Jog velocity"
Parameter No.48
"PIO inching distance"
ON
Parameter No.47
"PIO Jog velocity 2"
(Note 1)
Parameter No.47
"PIO Jog velocity 2"
Parameter No.49
"PIO inching distance 2"
Note 1: For direct numerical control mode, it operates at the following speed.
When speed setting value = 0 :
operates at the value of parameter No. 47 "PIO Jog velocity 2"
When speed setting value ≠ 0 : operates at the speed set value
(For details, see "3.7 Address Configuration / Direct numerical control mode assignment
(page A3-64).")
