2.2. Wiring
B2-9
ME0384-4A
Chapter 2 Mounting and Wiring
[Electric wire diameter used for RCON 24V power supply wiring]
For the wires to be connected to the power connector, use the following applicable wires.
Compatible wire
Signal name Content Compatible wire diameter
MP
24 V
Motor drive power supply AWG20 ~ 8 (Copper wire)
0 V
CP
24 V
Control power input AWG20 ~ 12 (Copper wire) 0 V
FG
* Use cables with their rated temperature on the isolation sheath at 60°C or higher.
The controller current consumption varies depending on the controller model and the motor type
of the actuator to be connected. Refer to "Specification Section Chapter 2, 2.3 Specifications/
Power supply capacity".
Caution
Using a cable with diameter less than the applicable cable diameter or wiring distance too
long may cause an error due to the voltage drop or may drop the actuator performance.
In such a case, have the output voltage of the power supply adjusted to 24V for the
controller supply voltage.
To Next Page
