4.1 How to Use the Gateway Parameter Configuration Tool
B4-19
ME0384-4A
Chapter 4 Network Configuration
(3) Select and click the communication speed setting value confirmed in (1).
Point!
● Here is how to set all the axes connected to the gateway unit to the same "operation
mode" collectively.
To individually set the "operation mode" of the connected axes, refer to "Specifications
Section 3.9 Gateway Parameter Configuration Tool/Operation mode setting (page A3-164)".
Parameter configuration tool" main screen
tool
Click
Select
To Next Page
