Table 36. General Policy settings (continued)
Name of setting Available values Comments
Protocol ID
v All
v TCP
v UDP
v ICMPv6
The Protocol ID defines for which IP
protocol type the policy is used.
Possible values are
v Any
All protocol types are selected
v ICMPv6
With ICMPv6, you can choose the
message type. Mainly for test and
certification.
– All/Echo Request (Ping
Send)/Echo Reply (Ping
Receive)/NS/NA
Note: NS = Neighborhood
Solicitation, NA =
Neighborhood Advertisement
Port Range
v From
v To
v All
v Custom
With TCP or UDP protocol, the
selector can be restricted to a range
of protocol ports.
Example: Only standard HTTP traffic
must be secured by IPSec.
v Protocol ID: TCP
v Port Range: 80 - 80
Address Range
v From
v To
v All
v Single
v Range
v Subnet
v Library Address
The Address Range defines for which
device addresses (mainly peer
addresses) the policy is selected.
v All
Any peer address trigger
v Single
Only the address that is defined in
the From: address fields trigger.
v Range
The Addresses between From: and
To: trigger.
v Subnet
All addresses in the subnet that is
defined by the From: field and the
Prefix length are used.
v Library Address
In case the device has multiple
local addresses (stateless/stateful),
an address can be selected by this
field. Only packets that are
dedicated for this local address are
selected.
140 IBM TS3100 Tape Library and TS3200 Tape Library: Setup, Operator, and Service Guide Machine Type 3573
