HORIZONTAL TAIL / HORIZONTAL TAIL TIP PIN 12-21
CHANGE C1 ICON A5 / MAINTENANCE MANUAL
5. Install the new pin by screwing it in first by hand to ensure that the threads are engaging properly,
then torque to 5-10 in-lb
f
. If this torque is insufficient to fully engage the pin, remove it, clean the
threads and reinstall.
6. Apply LOCITITE© 220™ to the base of the new pin after torquing. This is a wicking type of LOCI-
TITE© and it will be drawn into the threads. Wipe off any excess.
VERIFICATION METHOD:
After pin replacement, install the tip on the horizontal tail and verify correct fit and that the secure
wing/tail light on the pilot’s annunciator panel indicates correctly.
RELATED INFORMATION:
"Measure Horizontal Tail Tip Anti Rotation Pin Wear" on page 12-19
