12-20 HORIZONTAL TAIL / HORIZONTAL TAIL TIP PIN
ICON A5 / MAINTENANCE MANUAL CHANGE C1
CHAPTER 12
• Minimum pin diameter =.240”
RELATED INFORMATION:
"Horizontal Tail Tip Pin" on page 12-20
12.4.2 Maintenance Instructions
12.4.2.1 Horizontal Tail Tip Pin
Removing and replacing the horizontal tail tip pins.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
09—Horizontal Tail
Consumables
LOCTITE
®
220™
TASK INSTRUCTIONS:
1. Pull downward on the tip lock latch to remove it from the detent position and rotate the latch
approximately 180°.
2. Grasp the tip and slide it away from main horizontal tail until the cylindrical spar clears the struc-
ture.
3. Support the horizontal tail tip on a soft protective surface.
4. Two retaining pins protrude from the surface of the tip’s root rib. Each pin has flats to engage a
1/8 in open-end wrench. Remove a pin using a wrench to rotate the pin as one would a bolt or
stud. Ensure that the wrench fits securely and turn the pin carefully to avoid rounding off the flats.
