13-14 INSTRUMENTS (AND AVIONICS) / TROUBLESHOOTING
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 13
SECURE
WING/TAIL
LH or RH wing not secured. Secure LH/RH wing.
See “Install Left Wing” on page
17-12.
See “Install Right Wing” on page
17-14.
LH or RH wing lock switch
malfunction
Check for wire connections at the
switch. Verify actuator deactivates
light switch. Replace winglock
switch if necessary. See “Wing
Lock” on page 17-24.
LH or RH horizontal tail tip not
secured.
Secure LH/RH HT tip.
See “Horizontal Tail” on page 12-1.
LH or RH horizontal tail tip lock
switch malfunction.
Check for wire connections and
switch deactivates light switch.
Replace tail lock switch if
necessary. See “Remove Horizontal
Tail Tip Lock Switches” on page
12-6. See “Install Horizontal Tail Tip
Lock Switches” on page 12-16.
PURGE BILGE
More than 1 gallon in bilge. Run bilge pump.
See “Check Bilge Pump Function”
on page 6-42.
Trouble Light Possible Cause Remedy
