13-40 INSTRUMENTS (AND AVIONICS) / ANNUNCIATOR PANEL
ICON A5 / MAINTENANCE MANUAL CHANGE C2
ICA008907 (GRAPHIC OVERLAY, ANNUNCIATOR PANEL)
Aircraft System and Number
10—Instruments (and Avionics)
Consumables
None
NOTE: Retain removed hardware for re-installation.
1. Remove instrument cluster bezel. (See “Remove Instrument Cluster” on page 13-29.)
2. Remove four #4-40 screws attaching annunciator panel to mount.
3. Remove annunciator.
4. Replace with new PANEL, ANNUNCIATOR and re-install four attachment screws. Torque
screws to 2-4 in-lb. Check that hardware is secure.
CAUTION: PANEL, ANNUNCIATOR is an electrostatic sensitive device. Do not
open or handle except at a static-free work station.
5. Remove adhesive backing from GRAPHIC OVERLAY and apply to PANEL, ANNUNCIATOR.
6. Re-install instrument cluster into the aircraft. (See “Install Instrument Cluster” on page 13-31.)
VERIFICATION METHOD:
Check the operation of the annunciator panel (See “Annunciator Panel Function” on page 13-38.)
RELATED INFORMATION:
"Install Instrument Cluster" on page 13-31
"Remove Instrument Cluster" on page 13-29
"Annunciator Panel Function" on page 13-38
