13-64 INSTRUMENTS (AND AVIONICS) / VHF COMM ANTENNA
ICON A5 / MAINTENANCE MANUAL CHANGE C2
Aircraft System and Number
10—Instruments (and Avionics)
Consumables
None
The comm antenna is located on top of the horizontal tail.
1. Connect the antenna to the BNC connector.
2. Install antenna 4 8-32x1.00 screws.
VERIFICATION METHOD:
The task is finished when the antenna is fully installed.
