INSTRUMENTS (AND AVIONICS) / DAC MEMORY UNIT 13-65
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 13
13.7 DAC Memory Unit
13.7.1 Maintenance Instructions
13.7.1.1 DAC Memory Unit Removal
The A5 contains a memory unit that records data from operations. Use this task to remove the DAC
memory unit.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
2mm long-reach hex head wrench
Parts Required
None
Aircraft System and Number
10—Instruments (and Avionics)
Consumables
None
TASK INSTRUCTIONS:
1. Remove left side instrument panel cover (ICA001703) by carefully lifting up on the aft edge of
the cover to release the ball mounts from the rubber sockets. The cover’s forward edge is
retained by a plastic pin that slides aft out of a receptacle. Set the cover aside.
