13-66 INSTRUMENTS (AND AVIONICS) / DAC MEMORY UNIT
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 13
2. Locate the DAC912iS (ICA010394). It is mounted to the forward face of the right-side instrument
panel and can be reached through the instrument panel cover opening.
3. Remove the DAC memory unit (a 1 x1 x 2 inch cube) by removing the four retaining screws using
a 2mm long-reach hex wrench. Use care to avoid dropping screws. Retain the screws for
re-installation.
VERIFICATION METHOD:
Task is complete when DAC memory unit has been removed.
RELATED INFORMATION:
"DAC Memory Unit Re-Installation" on page 13-66
13.7.1.2 DAC Memory Unit Re-Installation
The A5 has a memory unit that records data from operations. Use this task to re-install the DAC
memory unit.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
10—Instruments (and Avionics)
Consumables
None
TASK INSTRUCTIONS:
1. Position the DAC memory unit such that the pins are facing aft, the two columns of pins are
vertical, and the pins are biased to left side of the aircraft, then re-insert the DAC SD card into
the DAC912iS unit. The card should slide easily in.
