13-70 INSTRUMENTS (AND AVIONICS) / PITOT-STATIC-ANGLE OF ATTACK (AOA) SYSTEM
ICON A5 / MAINTENANCE MANUAL CHANGE C2
13.8 Pitot-Static-Angle of Attack (AOA) System
RELATED INFORMATION:
"Remove Instrument Cluster" on page 13-29
13.8.1 Inspection Instructions
13.8.1.1 Pitot-Static-AOA Leak Test Procedures
Use the following procedures any time a pitot-static or AOA tube is disconnected. An alternative proce-
dure may be sued to test the pitot-static system only. The AOA system test must use a pitot-static test
unit.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
Preston PS-525 Pitot-Static Test Set (or equivalent)
ITW Tacky Tape
Parts Required
None
Aircraft System and Number
10—Instruments (and Avionics)
Consumables
None
The Preston PS-525 Pitot-Static Test Set is used to check for leaks in the pitot-static and AOA
systems. Other equivalent pitot-static test instruments may also be used, and the procedures for them
should be similar. When using a different test set, use these procedures as guide for test methodology
while referring to the manufacturer’s instructions.
It is acceptable to create connections using alternate means than shown in these procedures so long
as they are confirmed to be leak free.
It is preferable that a calibrated test set be used, but if not readily available, the pitot-static system can
be tested with simple tools such as a syringe. (See “Pitot Static Leak Check Operation” on page 13-75.)
