4. Use 1/2 and 3/8 wrenches to remove the AN5 bolt, nut, and washer that attach the MLG actuator
to the MLG bellcrank.
5. Use 1/2 and 3/8 wrenches to remove the AN5 bolt, nut, and washer that attach the MLG actuator
to the right MLG trunnion.
6. Remove the actuator from the aircraft being careful to not lose the actuator attach bushings.
There is a bushing in the motor-end of the actuator and another in the bellcrank.
VERIFICATION METHOD:
The task is complete when the actuator has been removed.
RELATED INFORMATION:
"Removal and Installation of Inspection Panels and Fairings" on page 3-34
14.6.1.9 Main Landing Gear (MLG) Actuator Installation
Use the following task to install the main landing gear (MLG) actuator.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
11—Landing Gear
Consumables
None
TASK INSTRUCTIONS:
1. Install an ICA008138 bearing into the attachment bore at the motor-end of the actuator.
2. Install an ICA008139 bushing into the above bearing.
