14-52 LANDING GEAR / MAIN LANDING GEAR
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 14
3. Install the motor-end of the actuator between the receiving ears on the MLG trunnion and install
the AN5C11A bolt with head facing forward. The limit switch assembly on the actuator should
face aft.
4. Install the NAS1149C0532R washer and MS21043-5 nut and using 1/2 and 3/8 wrenches, torque
to 85 in-lb
f
.
5. Install or verify the installation of the ICA008138 bearing and ICA008139 bushing in the actuator
ear on the MLG bellcrank.
6. Move the MLG leg until the holes in the fork-end of the actuator align with that of the ear of the
MLG bellcrank.
7. Install an ANC512A bolt through the assembly, attaching the actuator to the bellcrank. The head
should face aft.
8. Install the NAS1149C0532R washer and MS21043-5 nut and using 1/2 and 3/8 wrenches, torque
to 85 in-lb
f
.
9. Connect the actuator electrical connector to the aircraft harness.
10. Perform the MLG actuator rigging procedure.
11. Install the aft bulkhead baggage panel. (See “Baggage Sidewall Panel Installation” on page 3-45.)
12. Lower the aircraft from the jacks.
VERIFICATION METHOD:
Perform the MLG actuator rigging procedure.
14.6.1.10 Main Landing Gear (MLG) Rigging and Rigging Check with Landing Gear
Up
Use the following task to adjust the main landing gear (MLG) rigging when the landing gear is up.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
ICA009750 (Wing Jack Point Adapter)
Parts Required
None
Aircraft System and Number
