LANDING GEAR / NOSE LANDING GEAR 14-77
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
14.7.2.8 Nose Landing Gear (NLG) Rigging and Rigging Check with Landing Gear
Up
Use the following procedure to rig the NLG with the gear UP. See Step 7 for rigging check instructions.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
ICA009750 (Wing Jack Point Adapter)
Rig Pin (Dia. .1875 + .0100-.0000”)
Parts Required
None
Aircraft System and Number
11—Landing Gear
Consumables
None
1. Jack the aircraft up or weight the tail so that the nose gear is clear of the ground (use a safety
block under the forward hull if weighting the tail).
2. Using Test box, verify that when in full retract position, the NLG leg does NOT contact the NLG
stop.
3. Use Test box to position the NLG such that it is approximately half way between fully extended
and fully retracted.
4. Attach 5lb weight (ITL012297) to NLG wheel in the location shown.
