LANDING GEAR / AFT NOSE LANDING GEAR DOOR 14-91
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 14
11. Prepare door springs by attaching two spring clips onto the spring. Prepare a total of two of
these assemblies—one for the LH and one for the RH.
NOTE: Ensure the spring is connected to the smaller of the two holes on
the spring clip.
Qty Item No Part No
1 (9) 9654K196
2(25)ICA010385
