ICON A5 - Page 601

LANDING GEAR / AFT NOSE LANDING GEAR DOOR 14-93
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 14
13. Install the pushrod subassembly to the forward bellcrank. Connect the opposite side of the
pushrod subassembly to the RH forward bellcrank using the hardware shown. Torque to the
specification listed. Repeat for the mirror-image LH side.
Qty Item No Part No
1 (12) AN3C11A
1(18)ICA008887
1(29)MS21043-3
2 (31) NAS1149C0332R
1 (32) NAS1149C0363R
