ICON A5 - Page 603

LANDING GEAR / AFT NOSE LANDING GEAR DOOR 14-95
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 14
15. Install door spring to stud. Ensure that the CB200 applied to the click-bond stud is fully cured.
Connect the spring clip to the Click Bond stud and secure with the hardware shown. Torque to
the specification show. Repeat for the mirror-image LH side.
Qty Item No Part No
1 (8) 93013A605
1(29)MS21043-3
