14-96 LANDING GEAR / AFT NOSE LANDING GEAR DOOR
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 14
16. Insert bushings into the RH and LH aft bellcranks. Install the aft bellcranks into the RH and LH aft
bellcrank pockets as shown using the hardware listed. Torque all hardware as specified.
Qty Item No Part No
1(4)6362K112
1(23)ICA010059
2(5)75101
1(13)AN3C12A
1(29)MS21043-3
1(19)ICA010035
