LANDING GEAR / AFT NOSE LANDING GEAR DOOR 14-97
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 14
17. Install doors to the bellcranks by loosely installing the RH and LH doors to the bellcranks using
the hardware shown.
Qty Item No Part No
4(2)10F87MTT3/50TL
1 (26) ME000256
4(29)MS21043-3
4 (31) NAS1149C0332R
1 (27) ME000258
