WING / TROUBLESHOOTING 17-7
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
1. Remove all wing access panels (4).
2. Fold wings to expose wing fold tube.
3. Do a visual inspection through the wing fold ribs and access panels.
4. Using a borescope, flashlight, and viewing mirror as appropriate, visually inspect all accessible
bond lines for cracks or damage.
VERIFICATION METHOD:
Any cracks found should be investigation further. Do not fly the airplane and contact ICON for further
instructions.
