WING FOLD MECHANISM / TROUBLESHOOTING 18-3
CHANGE C0 ICON A5 / MAINTENANCE MANUAL
CHAPTER 18
18.2 Troubleshooting
18.2.1 Wing Fold Mechanism
Wing Fold Mechanism . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-3
Wing Fold Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-3
Wing Extend Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-4
Wing Fold/Extend Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-6
18.2.1.1 Wing Fold Procedure
Instructions to fold the wings.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
Owner/Pilot
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
15—Wing Fold Mechanism
Consumables
None
The manual wing fold system allows the wings to be rotated and folded back along the fuselage,
reducing the A5 width from approximately 35 feet to 8 feet for trailering, storage, and maintenance.
The wing fold mechanism was designed to be simple, allowing one person to complete the task in a
few minutes with no tools required using the following simple procedures.
WARNING: The handles built into the wing tips are to be used for wing folding
only. They must not be used for ground handling purposes or
pushing/pulling the entire aircraft.
TASK INSTRUCTIONS:
1. Set the parking brake or chock the wheels of the aircraft.
