19-24 ICON PARACHUTE SYSTEM (IPS) / EXTRACTION ROCKET
ICON A5 / MAINTENANCE MANUAL CHANGE C1
CHAPTER 19
RELATED INFORMATION:
"Removal and Installation of Inspection Panels and Fairings" on page 3-34
"Cockpit Panels Removal and Installation" on page 3-36
19.6.4 Maintenance Instructions
19.6.4.1 Extraction Rocket Removal
Use the following tasks to remove the extraction rocket system.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
16—ICON Parachute System (IPS)
Consumables
05-02687 (WIRE, SAFETY, SST, .041)
TASK INSTRUCTIONS:
1. Install the detent pin with the “REMOVE BEFORE FLIGHT” flag into the activation handle.
2. Carefully remove screw retaining activation cable into igniter. Unscrew the cone adapter (on the
end of the activation cable housing) from the rocket cone and GENTLY pull the cable from the
igniter/rocket cone.
NOTE: At the igniter, only 25-30lbs of force is required to ignite the rocket
assembly.
3. Remove rocket cone and install safety wire through small hole in igniter body and threaded hole
in actuator and tie to secure.
4. Remove the two shear screws retaining the pick-up collar onto the launch tube near the tip of the
rocket motor. Slide the pick-up collar off the rocket motor.
5. While supporting the rocket motor assembly, remove the screws that attach the rocket base to
the mounting shelf from underneath.
