ICON PARACHUTE SYSTEM (IPS) / EXTRACTION ROCKET 19-25
CHANGE C1 ICON A5 / MAINTENANCE MANUAL
CHAPTER 19
6. Carefully remove rocket assembly from canister and place in a cool, secure location.
NOTE: Do not return motor to BRS. It is illegal for non-licensed persons to
ship a loaded rocket motor by commercial carrier.
VERIFICATION METHOD:
The procedure is complete when the rocket system has been fully removed and placed in a secure
location.
RELATED INFORMATION:
"Removal and Installation of Inspection Panels and Fairings" on page 3-34
"Cockpit Panels Removal and Installation" on page 3-36
19.6.4.2 Extraction Rocket Assembly and Installation
Use the following tasks to install the extraction rocket system.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
1/4”-20 x 3/4 Button HD Cap SS
8-32 x 3/4 Screw
Aircraft System and Number
16—ICON Parachute System (IPS)
Consumables
LOCTITE
®
242™
TASK INSTRUCTIONS:
1. Mount the rocket pedestal with the rocket into the rocket bay. Secure the BRS 601 rocket
assembly to ICON’s rocket mounting bracket using two of the BRS provided 1/4”-20 x3/4 Button
HD Cap SS fasteners. Ensure that LOCTITE Blue 242 threadlocker is used to lock the fasteners
in place. The torque value for the fastners is 5.4lb-ft. The fitting between BRS 601 fixing to the
