ID Index Name / Setting Unit Description
twosteps
759 0 CON_
UnderVoltageThreshold
V Overwritedefaultundervoltagethresholdlevel
760  MON_VDC_Guard  MonitoringofDClinkvoltage
760 0 Tfilt_av ms Filtertimeconstantforaverage
760 1 Tfilt_var ms Filtertimeconstantforvariance
760 2 Max_var V^2 Maxallowedvariance
760 3 Max_time s Maxtimewithvariancethresholdexceeded
760 4 Check_time s Intervaltocheckreturnoffailedphase
1958 0 CON_FPGA_PWMScale % Phasevoltagescalingofthefpgacurrent
controller(0=noblockmodulation)
Table 4.1: “Power stage” parameters (continue)
ID Index Name / Setting Unit Description
307 0 CON_VoltageSupply  Powersupplymainsvoltage
  (-1)1/3x110V  Thedevicecanbeconnectedtothemainswith
oneorthreephases.
  (0)1x230V  Single-phasedevice
  (1)3x230V  Three-phasedevice
  (2)3x400V  Three-phasedevice
  (3)3x460V  Three-phasedevice
  (4)3x480V  Three-phasedevice
425 0 CON_GridVoltageNom V
r.m.s
Mainsvoltage
Table 4.2: “Power stage - AC drive controller ” parameters
ID Index Name / Setting Unit Description
307 0 CON_VoltageSupply  Powersupplymainsvoltage
  (5)Safetylowvoltage
24-60V
 
424 0 CON_VoltageMode  Devicepowersupplymode
425 0 CON_GridVoltageNom Vr.m.s Mainsvoltage
426 0 CON_
DCLinkVoltageNom
V DClinkvoltage(DClowvoltage)
Table 4.3: “Power stage - DC drives” parameters
ID No.: 0842.26B.5-01Date: 09.2020
ServoOne- Device Help
27
4 Power stage
ID Index Name Unit Description
308 0 CON_VoltageNom V Nominalvoltage(DClowvoltage)
Table 4.4: “Power stage - Low-voltage DC supply” parameters
ID Index Name Unit Description
425 0 CON_GridVoltageNom V
r.m.s
Mainsvoltage
2704 0 CON_WideRange  Usedtoactivatethewidevoltagerange–please
contactthemanufacturer!
Table 4.5: “Power stage - Mains voltage adaption” parameters
ID Index Name Unit Description
2940 0 CON_PowerFail_Sel  Powerfailurebridging:selector
2941  CON_POWF_VCtrl  Powerfailurebridging
2941 0 Kr A/V Powerfailurebridging:Gain
2941 1 Tn ms Voltagecontrolintegrationtimeconstant
2941 2 imax A Voltagecontrolmaximum(negative)q-current
2941 3 imax_pos A Voltagecontrolmaximumq-current
2941 4 n_min rpm Minimumspeed(absvalue)forvoltagecontrol
2942  CON_POWF_VLim  Voltagethreshold/referenceforpowerfail
2942 0 POWF_VOn V Thresholdvoltage(offset)tostartpowerfail
control
2942 1 POWF_VRef V Referencevoltage(offset)atpowerfail
2943 0 CON_POWF_RetTime ms uzkreturntime(65535=infinite)
2944 0 CON_POWF_UdcOffSw V Shutdownthreshold:Undervoltage
2945 0 CON_POWF_UbcOnSw V Switch-onthreshold:Brakingchopper
Table 4.6: “Power stage - Power failure bridging settings” parameters
