Remote RMX-3200 Version 5.2x Configuration Guide
Configuring Mediation Connections: Configuring an Asynchronous Serial to Asynchronous Serial
Connection
17-13
9. (optional) Verify that the serial controllers have been configured properly:
show controllers serial 1
The command response similar to the following displays:
show controllers serial 2
The command response similar to the following displays:
10. (optional) Manually connect a device to controller
serial 2 and send data.
11. (optional) Verify that a connection is established:
show connections
The command response similar to the following displays:
12. Save the configuration.
(Dub)>show controllers serial 1
serial 1 status=enabled link-state=down encapsulation= baud=9600 databits=8
stopbits=1 parity=none resource-state=unassigned
flow-control=none
linemode=rs232
dial-timer=1
init-string=
connect-mode= activity
rts-connect-mode=on
dtr-connect-mode=on
disconnect-mode=
rts-disconnect-mode=off
dtr-disconnect-mode=off
parity-errors=0
description=Asynchronous port
application=destination
(Dub)>
(Dub)>show controllers serial 2
serial 2 status=enabled link-state=down encapsulation= baud=9600 databits=8
stopbits=1 parity=none resource-state=unassigned
flow-control=none
linemode=rs232
dial-timer=1
init-string=
connect-mode=dcd
rts-connect-mode=on
dtr-connect-mode=on
disconnect-mode=
rts-disconnect-mode=off
dtr-disconnect-mode=off
parity-errors=0
description=Asynchronous port
application=source
(Dub)>
(Dub)>show connections
serial 2 -> serial 1
(Dub)>
