Remote RMX-3200 Version 5.2x Configuration Guide
Configuring the SNMP Proxy: Configuring a Mediation SNMP Measurement Template
22-12
6. Configure the varbind-match .1.3.6.1.4.1.539.42.2.2.1.1 for the critical
state; that is, the OID to use to retrieve the value of
$alIndex:
config mediation snmp measurement-template alDef trap critical
varbind-match .1.3.6.1.4.1.539.42.2.2.1.1 $alIndex
7. Configure a varbind value of for .1.3.6.1.4.1.539.42.2.2.1.5 for the
critical state:
config mediation snmp measurement-template alDef trap critical
varbind-value .1.3.6.1.4.1.539.42.2.2.1.5
8. Configure the template alDef to consider as significant the second numeric value
in a string response for
critical traps:
config mediation snmp measurement-template alDef trap critical
value-match 2
9. (optional) Verify that the point template has been configured properly:
show mediation snmp measurement-template alDef
The command response similar to the following displays:
10. Save the configuration.
To configure a mediation SNMP measurement template that configures a group of
measurements:
1. Configure the point template name
alTableDef:
config mediation snmp measurement-template alTableDef
2. (optional) Configure an associated description Measurement group:
config mediation snmp measurement-template alTableDef description
Measurement group
(Dub)>show mediation snmp measurement-templates alDef
Name: alDef
Description: Single measurement
Poll OID: .1.3.6.1.4.1.539.42.2.2.1.5.$(alIndex)
Value Match Index: 2
Value Conversion Multiplier: 1
Trap: critical
Trap OID: .1.3.6.1.4.1.539.42.2.0.5
Varbind Value: .1.3.6.1.4.1.539.42.2.2.1.5
Value Match Index: 2
Varbind Match: .1.3.6.1.4.1.539.42.2.2.1.1 = $alIndex
(Dub)>
