Device status register
The device status register set contains bits which give device-dependent
information.
The following bits in these registers are used by the U8480 Series:
Table 1-10 Bit definitions - Device status register
11 Lower Limit Fail This is a summary bit for the Lower Limit Fail Register
– SET:
If a measurement is made and the lower limit test fails
– CLEARED:
If a measurement is made and the lower limit test is not enabled or the test is enabled
and passes
12 Upper Limit Fail This is a summary bit for the Upper Limit Fail Register
– SET:
If a measurement is made and the upper limit test fails
– CLEARED:
If a measurement is made and the upper limit test is not enabled or the test is enabled
and passes
Bit number Definition EVENts causing bit changes
Bit number Decimal weight Definition
0 to 2 - Not Used
3 8 U8480 Series Error
4 to 14 - Not Used
15 - Not Used (always 0)
