MD-11 Flight Crew Operations Manual
k
Aircraft General -
Controls and Displays
Agen.30.14
Lavatory Door
CLOSE AND LATCH DOOR
FOR TAKEOFF AND LANDING
PLEASE LOCK DOOR
LOCKED
UNLOCKED
(DOOR INNER SURFACE)
LAVATORY DOOR (TYPICAL)
UNLOCKING KNOB
SLIDING BOLT LOCK
HINGED BEZEL SIGN
(NORMAL POSITION)
VACANT/OCCUPIED SIGN
DOOR LOCKED
DOOR UNLOCKED
HINGED BEZEL
SIGN (OPEN
POSITION)
LB1-3-0246
SLIDING BOLT LOCK
UNLOCKING KNOB
NO SMOKING
