MD-11 Flight Crew Operations Manual
k
Emergency Equipment -
Controls and Displays
Emer.30.19
Emergency Exits Cabin Doors - Manual Controls
LB1-3-0032
NOTE
ARMED
GIRT BAR
1
2
Door controls must be set for emergency
operation.
If door can not be opened using pneu-
matic power, pull door inboard at approx-
imately 45 degree angle and lift upward.
Release manual lift bar and push door
upward to full open position.
LEFT SIDE SHOWN. RIGHT SIDE OPPOSITE
November 16, 2009
