KLM MD-11 - Components; Airplane Dimensions

MD-11 Flight Crew Operations Manual
k
Aircraft General Chapter Agen
Components Section 20
Agen.20.1
Agen.20 Aircraft General-Components
Airplane Dimensions
DB1-2-1646
DB1-2-1646
200 FT 10 IN
(61.2 M)
GE ENGINE
201 FT 4 IN
(61.4 M)
59 FT 2 IN
80 FT 9 IN
(24.61 M)
192 FT 5 IN
169 FT 6 IN
(51.7 M)
(58.65 M)
(18.3 M)
P&W ENGINE
75 FT 10 IN
(23.1 M)
19 FT 9 IN
(6 M)
MAX 58 FT 10 IN (18.0 M)
MIN 56 FT 9 IN (17.3 M)
35 FT (10.7 M)
MAX 29 FT 2 IN (8.9 M)
MIN 28 FT 5 IN (8.7 M)
27 FT 10 IN
(8.5 M)
MAX 4 FT 5 IN (1.25 M)
MIN 3 FT 2 IN (1.00 M)
MAX 13 FT 4 IN (4.0 M)
MIN 12 FT 4 IN (3.8 M)
MAX 8 FT 5 IN (2.6 M)
MIN 7 FT 10 IN (2.4 M)
MIN
MAX
FWD DOOR
MID DOOR
OWING DOOR
AFT DOOR
15 FT 9 IN (4.8 M)
15 FT 8 IN (4.8 M)
15 FT 7 IN (4.7 M)
15 FT 0 IN (4.5 M)
17 FT 5 IN (5.3 M)
16 FT 11 IN (5.2 M)
16 FT 3 IN (5.0 M)
16 FT 3 IN (5.0 M)
(2.9 M)
9 FT 5 IN
27 FT 7 IN
(8.41 M)
October 02, 2006
